Household Refrigeration Light Commercial Refrigeration Mobile Refrigeration Heavy Commercial Refrigeration

Home Products & Solutions

N Series R600a Single Speed Compressor

The N series R600a fixed-speed compressor is Jiaxipera's best-selling product, with a maximum cooling capacity of 300W. This series incorporates multiple industry-leading technologies and features ultra-high efficiency, high reliability, low noise, and excellent matching performance. It is compatible with a wide range of refrigeration appliances such as household refrigerators, freezers, and ice makers, meeting everyday low-temperature refrigeration needs at home.

Product Advantages

Energy Efficient

Adopts high-efficiency pump body and valve assembly technology, delivering high cooling efficiency and effective energy savings.

Ultra-Low Noise

Optimized shell modal and vibration-damping structure result in low operating noise.

Durable and Reliable

Precision-engineered for wear resistance and long service life, enabling stable continuous operation over extended periods with a low failure rate.

SEND INQUIRY

Technical Specifications

Compressor Model	Displ.	Motor Type	Vol./Fre.	ooling Capacity				COP			Running Capacitor (µF)	Material of winding Main/Aux.
				ASHRAE			CECOMAF	ASHRAE		CECOMAF
				W	BTU/h	Kcal	W	W/W	BTU/Wh	W/W
	(cm3)		(V~/Hz）	W	BTU/h	Kcal	W	W/W	BTU/Wh	W/W
N1120Y	13.2	RSIR	220-240~/50	230	785	198	173	1.4	4.78	1.09	/	Al/Al
NT1121Y	14.2	RSCR	220-240~/50	249	850	214	187	1.55	5.29	1.21	4.0	Al/Al
NS1121Y	14.2	RSCR	220-240~/50	249	850	214	187	1.68	5.73	1.31	4.0	Al/Al
NX1119Y	12.1	RSCR	220-240~/50	215	734	185	161	1.80	6.14	1.40	4.0	Al/Al
NS1122Y	15.2	RSCR	220-240~/50	265	904	228	199	1.68	5.73	1.31	5.0	Al/Cu
NS1121Y*	14.2	RSCR	160-240~/50	249	850	214	187	1.68	5.73	1.31	6.0	Al/Al
NS1122Y*	15.5	RSCR	160-240~/50	265	904	228	199	1.68	5.73	1.31	6.0	Al/Al
NS1125Y*	16.8	RSCR	160-240~/50	300	1024	258	225	1.68	5.73	1.31	6.0	Al/Al
NX1122Y	15.2	RSCR	220-240~/50	265	904	228	199	1.85	6.31	1.44	4.0	Cu/Al
NX1125Y	16.8	RSCR	220-240~/50	300	1024	258	225	1.85	6.31	1.44	4.0	Cu/Al
NE1117Y	11.3	RSCR(ePTC)	220-240~/50	198	676	170	149	1.92	6.55	1.50	4.0	Al/Al
NN1110Y	6.7	RSCR(ePTC)	220-240~/50	117	399	101	88	2.02	6.89	1.58	2.0	Cu/Cu
NN1112Y	8.1	RSCR(ePTC)	220-240~/50	145	495	125	109	2.00	6.82	1.56	3.0	Cu/Cu
NN1114Y	9.6	RSCR(ePTC)	220-240~/50	172	587	148	129	2.00	6.82	1.56	4.0	Cu/Cu

Notes:

(1) All data is subject to change without notice.

Test conditions:	ASHRAE(℃)	CECOMAF(℃)
Evaporaring temp.	-23.3	-25
Condensing temp.	54.4	55
Subcooling temp.	32.2	55
Suction temp.	32.2	32.2
Ambient temp.	32.2	32.2
